Work Order Information

Customer Name: _______________________________________

Service Address: ______________________________________

PO Number: _______________________________________

Date of Service: ______________________________________

Technician Name: _____________________________________

Safety Verification

☐ Power disconnected before accessing wiring

☐ Appropriate PPE utilized

☐ Multimeter verified operational

☐ Meter set to AC Voltage (250V+ range)

Visual Inspection

Power Cord Condition

☐ No visible damage

☐ Damage observed

Comments:

Receptacle Condition

☐ No visible damage

☐ Damage observed

Comments:

Plug Connection

☐ Fully seated

☐ Loose connection

☐ Signs of overheating/discoloration

Comments:

MULTIMETER VERIFICATION

Before testing, verify the following:

☐ Meter set to AC Voltage

☐ Voltage range set to 250V or greater

☐ Meter functioning properly

☐ Test leads inspected

Identify the electrical ports

• Refer to the power cord diagram for correct placement of the probes.
• Use the provided reference image
• Note: Ground is the metal pad on the side of the plug


  Follow these measurement steps:

• Ground & Neutral

  • Place the multimeter probes in the ground and neutral ports.
  • Record the voltage reading (write it down).
  • Take a photo of the multimeter display.

    Voltage Measurements

Test #1 – Ground to Neutral

Ground & Neutral

• Place the multimeter probes in the ground and neutral ports.
• Record the voltage reading
• Take a photo of the multimeter display.
  Actual Reading: __________ VAC


Test #2 – L1 to L2

• Place the multimeter probes in the L1 and L2 ports.
• Record the voltage reading
• Take a photo of the multimeter display.
  Actual Reading: __________ VAC


Test #3 – Neutral to L1

• Place the multimeter probes in the Neutral and L1 ports.
• Record the voltage reading
• Take a photo of the multimeter display.
  Actual Reading: __________ VAC


Test #4 – Neutral to L2

• Place the multimeter probes in the Neutral and L2 ports.
• Record the voltage reading
• Take a photo of the multimeter display.
  Actual Reading: __________ VAC


Additional Diagnostics

Breaker Information

Breaker Size: __________ AMP

☐ Breaker operating normally

☐ Breaker tripped

☐ Breaker issue suspected

Comments:

Outlet Type Verified

☐ NEMA 14-30

☐ NEMA 14-50

☐ Other: __________________

Technician Assessment

☐ Incoming power within specification

☐ Incoming power out of specification

☐ Electrical supply issue suspected

☐ Sauna issue suspected

☐ Additional troubleshooting required

Comments:

Required Attachments

☐ Photo of Outlet

☐ Photo of Plug

☐ Ground-to-Neutral Reading

☐ L1-to-L2 Reading

☐ Neutral-to-L1 Reading

☐ Neutral-to-L2 Reading

☐ Additional Photos (if applicable)

Technician Certification

I certify that the above measurements were taken using a properly functioning multimeter and accurately represent the electrical readings observed at the time of service.

Technician Signature: ______________________________

Date: ______________________
